1.       N+L 18mm dual arc-extinction system

2.       Rated Voltage: 230V AC

3.       Rated Current: 6 10 16 20 25 32A

4.       Breaking Capacity: 4.5kA

5.       Standard Conformity: IEC:60898:1995

6.       Electrical/Mechanical Endurance: 4000(no. of operations)

7.       Type/Series: C (5-10In)  D (10-14In)

8.       Ambient Temperature: 30⁺⁵

9.       Tropical Test: Class 2 (relative humidity 95% at 55)

10.     Terminal Capacity(max): 10mm²

11.     Mounting: Clip on DIN Rail

12.     Patented in China
